NVIDIA ConnectX-6 Lx MCX623106AN-CDAT 25/50GbE OCP 3.0 SmartNIC - Dual-Port Ethernet Network Card
Datos del producto:
| Nombre de la marca: | Mellanox |
| Número de modelo: | Mcx623106an-cdat |
| Documento: | connectx-6-lx-en-card.pdf |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 Uds. |
|---|---|
| Precio: | negotiable |
| Detalles de empaquetado: | Caja de cartón |
| Tiempo de entrega: | Basado en el inventario |
| Condiciones de pago: | T/T |
| Capacidad de la fuente: | Suministro por proyecto/lote |
|
Información detallada |
|||
| Estado de productos: | Existencias | Condición: | Nuevo y original |
|---|---|---|---|
| Tiempo de garantía: | 1 año | Tecnología: | Éternet |
| Interfaz de red: | Dos carriles SERDES que admiten 25 GB/s por carril, para varias configuraciones de puerto: -2x 10/25 | Velocidad: | 25 Gbps |
| Interfaz: | QSFP56 | Tasa de enlace: | 16.0 gt/s |
| Resaltar: | NVIDIA ConnectX-6 Lx 25/50GbE SmartNIC,Dual-Port Ethernet Network Card OCP 3.0,Mellanox ConnectX-6 Lx network card with warranty |
||
Descripción de producto
The MCX623106AN-CDAT network card delivers exceptional 25/50GbE connectivity with advanced security features and accelerated networking capabilities. This high-performance NIC card is engineered for modern enterprise data centers requiring scalable, secure, and efficient network infrastructure.
- Dual-port 25GbE or single-port 50GbE configuration
- Hardware-accelerated IPsec encryption
- Zero-Touch RoCE for simplified deployment
- SDN offloading with ASAP² technology
- Hardware root-of-trust security
The NVIDIA ConnectX-6 Lx Ethernet SmartNIC (model MCX623106AN-CDAT) represents a significant advancement in network interface card technology. This intelligent network card provides robust 25/50GbE connectivity with comprehensive security features and acceleration capabilities.
- Advanced RoCE capabilities for efficient data transfer
- SDN acceleration with ASAP² technology
- IPsec inline crypto acceleration
- Overlay tunneling accelerations
- Stateful rule checking for connection tracking
- Hardware root-of-trust and secure firmware update
- 75Mpps message rate at line speed
- Support for PCIe Gen3 and Gen4 interfaces
This advanced network card incorporates NVIDIA's ASAP² (Accelerated Switch and Packet Processing) technology, which offloads SDN data plane operations to the SmartNIC. The solution features Zero-Touch RoCE (ZTR) technology, enabling RDMA over Converged Ethernet without requiring specialized network configuration.
The MCX623106AN-CDAT network card is ideally suited for:
- Cloud data centers requiring high-performance virtualization
- Enterprise networks deploying software-defined infrastructure
- High-performance computing clusters
- Storage area networks leveraging RDMA technology
- Network function virtualization (NFV) implementations
- Big data analytics environments
- AI and machine learning workloads
| Parameter | Specification |
|---|---|
| Product Model | MCX623106AN-CDAT |
| Network Interface | 2x 25GbE or 1x 50GbE |
| Host Interface | PCIe Gen4 x8 |
| Data Rate | Up to 50 Gb/s total bandwidth |
| Form Factor | OCP 3.0 Small Form Factor |
| Connector Type | SFP28 |
| Power Consumption | Typical: 12W, Maximum: 15W |
| Operating Temperature | 0°C to 55°C |
We provide comprehensive support for all our networking products, including this advanced network card. Our services include:
- Standard 3-year manufacturer warranty
- 24/7 technical support and consultation
- Rapid delivery with extensive inventory
- Custom configuration services
- Integration support for complex deployments
The MCX623106AN-CDAT network interface card is compatible with servers supporting PCIe Gen3 or Gen4 interfaces and the OCP 3.0 SFF form factor. It supports both x86 and Arm architectures with UEFI firmware.
Yes, this network card features SR-IOV technology that enables direct assignment of virtual functions to virtual machines or containers, significantly improving virtualization performance.
- Ensure proper airflow for thermal management in high-density deployments
- Verify server compatibility with OCP 3.0 SFF form factor
- Update to latest firmware for full feature availability
- Consult compatibility matrix for specific switch interoperability
- Follow ESD precautions during installation
- Ensure adequate power supply capacity for full functionality
